Micro SD Breakout Board

IC Breakout, LLC

$9.95
SKU: ICB00415

The MicroSD breakout board is a DIP adapter for the Micro SD connector.  This board has all of the support components to use a Micro SD card.  You don't need to add any pull-up resistors or a power decoupling capacitor, it's already on the board for you! Also, the SD card hangs over for easy removal and insertion.

Technical Details

Footprint Dimensions

Body (mm):

n/a

Pitch (mm):

n/a

Thermal Pad (mm):

n/a

Breakout Board Dimensions

Board Dimensions (mil):

780 x 507

Board Thickness (mil):

62

Through-Hole Spacing (mil):

100 mil (X-axis)

n/a (Y-axis)

Breakout Board Specifications

Board Layers:

2

Finish:

Immersion Gold

Copper:

1 oz

Traces (mil):

10

Trace Lengths (mil):

<150

Pin/Through-Hole Count:

8

What's Included?

Parts Installed on Board:

MicroSD connector,

100k resistor array,

.1uF capacitor,

100K resistor

Parts Included

(but not installed):

8 PIN Break Away Header (Straight)

Additional Features

    • Easily identifiable PIN 1 indicator and PIN numbers
    • White silk “Label Pads” allow you to label the pins for quick reference
    • Extended through-hole pads make for an easy connection point for surface mount parts
    • Breadboard friendly pin spacing
    • All boards have been E-tested for failures and are RoHS compliant
…More details on our additional features can be found HERE

Documentation

(includes a 1:1 Scale Image of the board to ensure that it will be a good fit for your project!)
